16 Channel 4K 5MP CP Plus DVR CP-UVR-1601L1N-4KI3-V2

Original price was: ₹35,000.00.Current price is: ₹16,500.00.

Installation and AMC service available throughout Hyderabad/Telangana.

We also provide wide range of CCTV cameras, installation and AMC service available throughout Hyderabad/Telangana

16 Channel 4K 5MP CP Plus DVR CP-UVR-1601L1N-4KI3-V2

  • Supports HDCVI/AHD/TVI/CVBS/IP video inputs
  • Support upto 8MP IP Camera
  • Instastream/ H.265 dual-stream video compression
  • Max 32 channels IP camera inputs, each channel up to 8MP; Max 128 Mbps incoming bandwidth
  • Support 1 SATA HDD up to 16TB, 2 USB Ports
  • 1 HDMI / 1 VGA simultaneous video output
  • Up to 16 channels video stream (analog channel) SMD Plus
  • Mobile Software: iCMOB, gCMOB
  • CMS Software: KVMS, KVMS Pro

One day Installation Available
Free delivery
1 years onsite service
1years warranty

10 days replacement

Return and Replacement policy

Click Here For Same Day Installation and Discounts

Get Quote & Free Demo

16 Channel 4K 5MP CP Plus DVR CP-UVR-1601L1N-4KI3-V2

16 Channel 4K 5MP CP Plus DVR CP-UVR-1601L1N-4KI3-V2

PRODUCTLINK: CP-UVR-1601L1N-4KI3-V2 (cpplusworld.com)

System Overview
This Series has gathered momentum across the globe
for its outstanding performance and premium recording quality as it can be applied in any situation for IP video surveillance. This Series supports the input, recording and transmission functions. Along with that, this DVR also enjoys the help of a built-in deep learning module as this product adopts the video image that is structured on deep learning algorithms. This DVR lets you achieve high-precision human face recognition and efficient perimeter protection. This product has been crafted to pay attention to what matters the most through applying deep learning artificial intelligence, which makes it fasten the event response time and helps in making the video more actionable.

Functions
Face Recognition
This technology is just the most proficient element of the current video surveillance industry as the DVRs that have been integrated with the real-time face recognition technology accurately detects facial attributes in the video stream in real-time. The technology analyzes every facial attribute ranging from gender, age, expression to wearing glasses, mask, and even mustaches.
gCMOB/ iCMOB
Designed to allow users to access and control live streaming from CP PLUS IP Cameras, DVRs/ NVRs and Video Door Phones, the CP PLUS gCMOB/ iCMOB application offers a host of features such as Easy GUI, up to 16 live viewing split-ups; Instron cloud support; Playback; digital zoom ins; two-way talk, and more.
KVMS/ KVMS Pro
The KVMS/ KVMS Pro is a hybrid security management software that allows the management of various surveillance devices such as cameras, DVRs/ NVRs, encoders/ decoders, etc. It is released with the surveillance hardware and exclusively supports CP PLUS devices.

Interstream
This camera has been designed with the latest and most efficient innovation among the standard video compression designs. Smart encoding algorithms developed by CP PLUS help in saving up to 70% more bandwidth than H.265 along with making it more beneficial for minimizing bandwidth and storage costs. It enhances video coding efficiency while providing high resolution and the rate of frame in the video using Intelligent Region Perception to detect motion in each frame.

Processor Industrial-Grade Processor
Analog Camera Input 16 BNC ports, supports HDCVI/AHD/TVI/CVBS auto-detect
User Interface Web; Local GUI
IP Camera Input Up to 32 channels of IPC access 16 IP channels by default + 16 channels (analog channels are converted to IP channels) incoming bandwidth: 128 Mbps, recording bandwidth: 128 Mbps and outgoing bandwidth: 128 Mbps *After IP channels are added beyond the existing channels, the AI Function (IVS, SMD, FACE) will be disabled
Operating System Embedded Linux
Camera Input 1. CVI: 4K@25/30 fps; 6 MP@20 fps; 5 MP@20 fps; 5 MP@25 fps; 4 MP@25/30 fps; 1080p@25/30 fps; 720p@25/30 fps; 720p@50/60 fps.2. TVI: 4K@15 fps; 5 MP@20 fps; 4 MP@25/30 fps; 3 MP@25/30 fps; 1080p@25/30 fps; 720p@25/30 fps.3. AHD: 4K@15 fps; 5 MP@20 fps; 4 MP@25/30 fps; 3 MP@25/30 fps; 1080p@25/30 fps; 720p@25/30fps
Two-way Talk Support (share the same audio input with the first channel)
Video Output 1 HDMI, 1 VGA HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 *Simultaneous/heterogeneous video sources output for VGA and HDMI is configurable
Face Attributes Gender; Age group; Glasses; Expressions; Face mask; Beard
Face Database Capacity Up to 10 face databases with 20,000 face images in total. Name, Gender, Birthday, Address, Certificate type, Certificate No., Countries & Regions and state can be added to each face image
Video Compression H.265, H.264
Frame Rate Main stream: 4K@(1fps-7fps); 6 MP@(1fps-10fps); 5 MP@(1fps-12fps); 4K-N, 4 MP, 3 MP@ (1fps-15fps); 4M-N, 1080p, 720p, 960H, D1,CIF@(1fps–25/30fps); Sub stream: 960H@(1fps– 15fps); D1/CIF@(1 fps– 25/30fps)
Encode Strategy AI Instastream/ Instastream
stream Capability Dual Stream
Perimeter Performance of AI by DVR (Number of Channels) Advanced Model: 2 channels, 10 IVS for each channel General Model: 8 channels, 10 IVS for each channel
Face Recognition Performance of AI by DVR (Number of Channels) 2 Channels
Face Detection Performance of AI by DVR (Number of Channels) 2 Channels (up to 12 face images/s each channel)
Bit Rate 32 kbps–6144 kbps
SMD Plus by DVR 16 channels: Secondary filtering for human and motor vehicle , Reducing false alarms caused by leaves, Rain and lighting condition change
Audio Input 1-channel RCA ,16-channel BNC (Coaxial Audio)
Audio Output 1 Channel RCA
Audio Compression G.711a; G.711u; PCM
Audio Sample Rate 8 kHz, 16 bit
Hard Disk 1 SATA port, up to 6TB capacity for each disk. The maximum HDD capacity varies with environment temperature.
Smart Phone iPhone, iPad, Android Phone
General Alarm Motion detection; Video loss; Tampering
Audio Bit Rate 64 kbps
Anomaly Alarm No disk; Storage error; Disk full; Camera offline; IP conflict; MAC conflict
Intelligent Alarm Face detection; Face recognition; Perimeter protection
Alarm Linkage Record; Snapshot (panoramic); IPC external alarm output; Access controller; Voice prompt; Buzzer; log; Preset; Email
Recording Playback 1/4/9/16
Browser Chrome, IE9 or later, Firefox
Backup Method USB device and Network
Recording Mode General, Motion detection; Intelligent; Alarm; POS
Playback Instant playback, General playback, Event playback, Tag playback, Smart playback (face and motion detection)
Interface Ports 1 HDMI, 1 VGA, 1 RS485, 2 USB Ports( (1 front USB 2.0 port, 1 rear USB 3.0 port)
Network Mode Single-address mode
Ethernet 1 RJ-45 Port ((10/100/1000Mbps)
Protocols HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; SMTP; NTP; DHCP; DNS; DDNS; ONVIF 22.12(Profile T; Profile S; Profile G); CGI; SDK
Power Supply DC12V, 3Amp
Power Consumption <15W (Without HDD)
Operating Temperature -10 ~+55°C
Operating Humidity 10%–90% (RH)
Dimension 325 mm × 257.1 mm × 55.0 mm
Weight 1.5Kg

16 Channel 4K 5MP CP Plus DVR CP-UVR-1601L1N-4KI3-V2, CCTV surveillance, CCTV camera, Security systems, Interactive panels, Whiteboard, Discount offers available. You may visit Shop, same day Installation

Search Term

Hikvision CCTV camera  CP Plus Camera  Dahua IP Camera  Wireless 360 camera  Human detection camera  Dlink Ptz camera  Hawkvision IP Bullet camera  Honeywell IP down camera  Biometric attendance  Door access control  Timewatch Glass door access control  Essl Door Access  Biomax Biometric  Automatic school bell  School bell  Vamaa Digital board  DG board  Interactive white panel  Evota Interactive 4K flat panel  Infrared Interactive white board  Cornea Smart classroom equipment  School solutions  Audio broadcast system  Two way audio broadcast  School audio broadcast  Benq Projector for classroom  LG theatre projector  CCTV monitors  Surveillance hard disk Seagate CCTV hard disk Money counting machine  POE switch  Parking solution  Video door phone  Boom barriers  Flap barriers  X-ray baggage scanner  Smart door lock  School accessories  Intercom  Fire and safety

Reviews

There are no reviews yet.

Be the first to review “16 Channel 4K 5MP CP Plus DVR CP-UVR-1601L1N-4KI3-V2”

FAQs

What is the maximum resolution supported by this DVR?
The CP-UVR-1601L1N-4KI3-V2 supports a maximum resolution of 4K (8MP) for ultra-high-definition video quality.
How many channels does this DVR support?
This DVR supports 16 channels, allowing connectivity for up to 16 cameras for extensive surveillance coverage.
What is the storage capacity of this DVR?
Equipped with multiple SATA interfaces, this DVR can accommodate multiple hard drives for storage. The storage capacity depends on the capacity of the hard drives installed.
