24Port 100Mbps and 2Port Gigabit Managed PoE Switch Dahua DH-PFS4226-24ET-240
37%
off

24Port 100Mbps and 2Port Gigabit Managed PoE Switch Dahua DH-PFS4226-24ET-240

Original price was: ₹30,000.00.Current price is: ₹18,800.00.

Installation and AMC service available throughout Hyderabad/Telangana.

We also provide wide range of CCTV cameras, installation and AMC service available throughout Hyderabad/Telangana

24Port 100Mbps and 2Port Gigabit Managed PoE Switch Dahua DH-PFS4226-24ET-240

> Intelligent PoE

> Red port supports 90W IEEE802.3bt
> Web management with friendly interface and easy operation
> 250 m long distance PoE transmission
> PoE watchdog
> Plug and play

One day Installation Available
Free delivery
1 years onsite service
1years warranty

10 days replacement

Return and Replacement policy

Click Here For Same Day Installation and Discounts

Get Quote & Free Demo

ENQUIRY NOW

24Port 100Mbps and 2Port Gigabit Managed PoE Switch Dahua DH-PFS4226-24ET-240

24Port 100Mbps and 2Port Gigabit Managed PoE Switch Dahua DH-PFS4226-24ET-240

PRODUCTLINK: PFS4226-24ET-240 | Dahua Technology (dahuasecurity.com)

Technical Specifications

Performance
Layer Layer 2
Managed Yes
Switching Capacity 8.8 Gbps
Packet Forwarding Rate 6.55 Mpps
Packet Buffer Memory 2.75 Mbit
MAC Table Size 4K
Communication Standard IEEE802.3; IEEE802.3u; IEEE802.3x; IEEE 802.3ab;

IEEE 802.3z
Hardware Feature
Standard Power Supply Yes
PoE Yes
Ethernet Port 24
Optical Port 2
Ethernet Port Rate 100 Mbps
Optical Port Rate 1 Gbps
Number of Bussiness Card Slots Port 1-24: 24 × RJ-45 10 M/100 M (PoE)
Port 25-26: 2 × RJ-45 10 M/100 M/1000 M (uplink)
Port 25-26: 2 × SFP 1000 M (uplink) (combo)
Debugging Console × 1
Power Supply 100V–240V AC
Operating Temperature –10 °C to +55 ° (14 °F to 131 °F)
Operating Humidity 10% RH–90% RH
Power Consumption Idling: 10W
Full load: 240W
PoE
PoE Standard IEEE802.3af/ IEEE802.3at/ Hi-PoE/IEEE802.3bt
PoE Budget Port 1-2 ≤ 90W, Port 3-24 ≤ 30W, total ≤ 240W
PoE Pin Assignment 1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-)
PoE Management Power consumption management
Power on and power off
Power down for overload
Green PoE
Legacy support
Long Distance PoE Transmission 250 m long-distance power supply
Function
Spanning Tree Protocol IEEE 802.1d (STP); 802.1w (RSTP)
VLAN IEEE802.1q Standard VLAN
Flow Control Support IEEE 802.3x (full duplex flow control) and back pressure flow control (half duplex)
Link Aggregation Static; LACP
Port Mirroring One-to-one; multiple-to-one
Multicast GMP snooping based on port
DHCP DHCP client
Security Hardware supports IP and MAC binding based on port, MAC filtering based on port, and IEEE802.1x port authentication
QoS High and low priority
WRR
802.1P
DSCP
Priority based on protocol
General
ESD Air discharge: 8kV
Contact discharge: 6kV
Thunder-proof Common mode: 4kV
Differential mode: 2kV
Dimensions 440 mm × 300 mm × 44 mm (17.32″ × 11.81″ × 1.73″) (L × W × H)
Packaging Dimensions Packing box: 527 mm × 412 mm × 110 mm (20.75″ × 16.22″ × 4.33″) (L × W × H)
Protective box: 584 mm × 549 mm × 446 mm (22.99″ × 21.61″ × 17.56″) (L × W × H)

24Port 100Mbps and 2Port Gigabit Managed PoE Switch Dahua DH-PFS4226-24ET-240, CCTV surveillance, CCTV camera, Security systems, Interactive panels, Whiteboard, Discount offers available. You may visit Shop, same day Installation

Search Term

Hikvision CCTV camera  CP Plus Camera  Dahua IP Camera  Wireless 360 camera  Human detection camera  Dlink Ptz camera  Hawkvision IP Bullet camera  Honeywell IP down camera  Biometric attendance  Door access control  Timewatch Glass door access control  Essl Door Access  Biomax Biometric  Automatic school bell  School bell  Vamaa Digital board  DG board  Interactive white panel  Evota Interactive 4K flat panel  Infrared Interactive white board  Cornea Smart classroom equipment  School solutions  Audio broadcast system  Two way audio broadcast  School audio broadcast  Benq Projector for classroom  LG theatre projector  CCTV monitors  Surveillance hard disk Seagate CCTV hard disk Money counting machine  POE switch  Parking solution  Video door phone  Boom barriers  Flap barriers  X-ray baggage scanner  Smart door lock  School accessories  Intercom  Fire and safety

Reviews

There are no reviews yet.

Be the first to review “24Port 100Mbps and 2Port Gigabit Managed PoE Switch Dahua DH-PFS4226-24ET-240”

FAQs

What are the key features of the Dahua DH-PFS4226-24ET-240 switch?
The DH-PFS4226-24ET-240 offers 24 100Mbps PoE ports, 2 Gigabit ports, advanced management capabilities, and robust power delivery for PoE-enabled devices.
What management features does this switch provide?
This switch offers features such as VLAN support, Quality of Service (QoS), port mirroring, SNMP for monitoring, and more, providing administrators with greater control over network traffic.
What is the power budget for the PoE ports?
The power budget varies; however, it's essential to check the specific datasheet or user manual for accurate information about the power budget of the DH-PFS4226-24ET-240 switch.
Can this switch be rack-mounted?
Yes, the DH-PFS4226-24ET-240 is typically designed for rack-mounting, facilitating easy installation in standard network equipment racks.
